SCONI-3DST3路信号分配器3CHANNEL SIGNAL DISTRIBUTOR

SCONI-3DST3路信号分配器3CHANNEL SIGNAL DISTRIBUTOR

General
This model is a distributor which inputs
various signal and outputs isolated 3 output.
Also, it is used in narrow space widely.

Order information
SCONI - 3DST - □ □ □ □ - □
􀁺 Input signal
􀁺 Output signal (1)
􀁺 Output signal (2)
􀁺 Output signal (3)
􀁺 Power supply
Item Specification
Input DC current, voltage, RTD, PMC, 2
Wire
Output Various DC current, voltage
Tolerance ± 0.2% Max.
Linearity ± 0.02% F.S
Response
Time Less than 0.5sec(0~90%)
Temperature
Coefficient ± 0.015% / ℃
Output
adj Range
ZERO ± 20%
SPAN ± 20% of F.S
Isolation More than 100㏁(DC 500V)
Dielectric
Strength Input/Output/Power, AC 1500V / min
AC 110/220V ±10% 50/60Hz 3VA
Power Supply
DC 24V ±10%, Less than 100mA
Operating
Temperature 0 ~ 55℃
Operating
Humidity 20 ~ 80%
Weight Approx 400gr(AC), 250gr(DC)
Material/Color ABS Resin / Black
Dimension W48 x H80 x D102 (mm)
Mounting Wall or DIN Rail
A RTD
B Potentiometer
C 2 Wire
D DC 0 ~ 10V
E DC 1 ~ 5V
F DC 0 ~ 20mA
G DC 4 ~ 20mA
R Other
1 DC 0 ~ 10V
2 DC 1 ~ 5V
3 DC 0 ~ 20mA
4 DC 4 ~ 20mA
R Other
􀂄 General
This model is a distributor which inputs
various signal and outputs isolated 3 output.
Also, it is used in narrow space widely.
X AC 110V/220V
Y DC 24V
1 DC 0 ~ 10V
2 DC 1 ~ 5V
3 DC 0 ~ 20mA
4 DC 4 ~ 20mA
R Other
1 DC 0 ~ 10V
2 DC 1 ~ 5V
3 DC 0 ~ 20mA
4 DC 4 ~ 20mA
R Other
